The stream informations about a decompressed packet. More...
Data Fields | |
| rohc_cid_type_t | cid_type |
| bool | cid_found |
| rohc_cid_t | cid |
| bool | context_found |
| struct rohc_decomp_ctxt * | context |
| rohc_profile_t | profile_id |
| rohc_mode_t | mode |
| bool | do_change_mode |
| rohc_decomp_state_t | state |
| uint32_t | sn_bits |
| size_t | sn_bits_nr |
| rohc_packet_t | packet_type |
| bool | crc_failed |
Detailed Description
The stream informations about a decompressed packet.
To be able to send some feedback to the compressor, the decompressor shall (aside the decompression status itself) collect some informations about the packet being decompressed:
- the Context ID (CID) of the packet (even if context was not found)
- the CID type of the channel
- the ID of the decompression profile
- if context was found, the context mode
- if context was found, the context state
- if context was found, the SN (LSB bits) of the latest successfully decompressed packet
- the packet type if available
Field Documentation
| rohc_cid_t rohc_decomp_stream::cid |
The CID of the packet
| bool rohc_decomp_stream::cid_found |
Whether the CID of the packet was found or not
| rohc_cid_type_t rohc_decomp_stream::cid_type |
The CID type of the channel
| struct rohc_decomp_ctxt* rohc_decomp_stream::context |
The decompression context, if found
| bool rohc_decomp_stream::context_found |
Whether the context was found or not
| bool rohc_decomp_stream::crc_failed |
Whether the packet failed the CRC check or not
| bool rohc_decomp_stream::do_change_mode |
The context mode shall be advertised
| rohc_mode_t rohc_decomp_stream::mode |
The context mode (if context found)
| rohc_packet_t rohc_decomp_stream::packet_type |
The type of the decompressed packet
| rohc_profile_t rohc_decomp_stream::profile_id |
The decompression profile (ROHC_PROFILE_GENERAL if not identified)
| uint32_t rohc_decomp_stream::sn_bits |
The SN LSB bits (if context found)
| size_t rohc_decomp_stream::sn_bits_nr |
The number of SN LSB bits (if context found)
| rohc_decomp_state_t rohc_decomp_stream::state |
The context state (if context found)
The documentation for this struct was generated from the following file:
