Data Fields | |
| uint16_t | msn |
| struct c_wlsb | msn_wlsb |
| uint16_t | msn_of_last_ctxt_updating_pkt |
| struct c_wlsb | innermost_ip_id_offset_wlsb |
| ip_context_t | ip_contexts [ROHC_MAX_IP_HDRS] |
| size_t | ip_contexts_nr |
| uint8_t | all_df_trans_nr |
| uint8_t | innermost_df_trans_nr |
| uint8_t | outer_df_trans_nr |
| uint8_t | all_ip_id_behavior_trans_nr |
| uint8_t | innermost_ip_id_behavior_trans_nr |
| uint8_t | outer_ip_id_behavior_trans_nr |
| uint8_t | innermost_ip_flag_trans_nr |
| uint8_t | outer_ip_flag_trans_nr |
| uint8_t | innermost_tos_tc_trans_nr |
| uint8_t | innermost_ttl_hopl_trans_nr |
| struct comp_rfc5225_tmp_variables | tmp |
| uint16_t | udp_sport |
| uint16_t | udp_dport |
| bool | udp_checksum_used |
| uint8_t | udp_checksum_used_trans_nr |
Detailed Description
Define the ROHCv2 IP/UDP part of the profile compression context
Field Documentation
◆ all_df_trans_nr
| uint8_t rohc_comp_rfc5225_ip_udp_ctxt::all_df_trans_nr |
The number of all DF transmissions since last change
◆ all_ip_id_behavior_trans_nr
| uint8_t rohc_comp_rfc5225_ip_udp_ctxt::all_ip_id_behavior_trans_nr |
The number of all IP-ID behavior transmissions since last change
◆ innermost_df_trans_nr
| uint8_t rohc_comp_rfc5225_ip_udp_ctxt::innermost_df_trans_nr |
The number of innermost DF transmissions since last change
◆ innermost_ip_flag_trans_nr
| uint8_t rohc_comp_rfc5225_ip_udp_ctxt::innermost_ip_flag_trans_nr |
The number of innermost IP flag transmissions since last change
◆ innermost_ip_id_behavior_trans_nr
| uint8_t rohc_comp_rfc5225_ip_udp_ctxt::innermost_ip_id_behavior_trans_nr |
The number of innermost IP-ID behavior transmissions since last change
◆ innermost_ip_id_offset_wlsb
| struct c_wlsb rohc_comp_rfc5225_ip_udp_ctxt::innermost_ip_id_offset_wlsb |
The W-LSB encoding context for innermost IP-ID offset
◆ innermost_tos_tc_trans_nr
| uint8_t rohc_comp_rfc5225_ip_udp_ctxt::innermost_tos_tc_trans_nr |
The number of innermost TOS/TC transmissions since last change
◆ innermost_ttl_hopl_trans_nr
| uint8_t rohc_comp_rfc5225_ip_udp_ctxt::innermost_ttl_hopl_trans_nr |
The number of innermost TTL/HL transmissions since last change
◆ ip_contexts
| ip_context_t rohc_comp_rfc5225_ip_udp_ctxt::ip_contexts[ROHC_MAX_IP_HDRS] |
◆ ip_contexts_nr
| size_t rohc_comp_rfc5225_ip_udp_ctxt::ip_contexts_nr |
◆ msn
| uint16_t rohc_comp_rfc5225_ip_udp_ctxt::msn |
The Master Sequence Number (MSN)
◆ msn_of_last_ctxt_updating_pkt
| uint16_t rohc_comp_rfc5225_ip_udp_ctxt::msn_of_last_ctxt_updating_pkt |
The MSN of the last packet that updated the context (used to determine if a positive ACK may cause a transition to a higher compression state)
◆ msn_wlsb
| struct c_wlsb rohc_comp_rfc5225_ip_udp_ctxt::msn_wlsb |
The W-LSB encoding context for MSN
◆ outer_df_trans_nr
| uint8_t rohc_comp_rfc5225_ip_udp_ctxt::outer_df_trans_nr |
The number of outer DF transmissions since last change
◆ outer_ip_flag_trans_nr
| uint8_t rohc_comp_rfc5225_ip_udp_ctxt::outer_ip_flag_trans_nr |
The number of outer IP flag transmissions since last change
◆ outer_ip_id_behavior_trans_nr
| uint8_t rohc_comp_rfc5225_ip_udp_ctxt::outer_ip_id_behavior_trans_nr |
The number of outer IP-ID behavior transmissions since last change
◆ tmp
| struct comp_rfc5225_tmp_variables rohc_comp_rfc5225_ip_udp_ctxt::tmp |
◆ udp_checksum_used
| bool rohc_comp_rfc5225_ip_udp_ctxt::udp_checksum_used |
Whether the UDP checksum is used or not
◆ udp_checksum_used_trans_nr
| uint8_t rohc_comp_rfc5225_ip_udp_ctxt::udp_checksum_used_trans_nr |
The number of 'UDP checksum used' transmissions since last change
◆ udp_dport
| uint16_t rohc_comp_rfc5225_ip_udp_ctxt::udp_dport |
The UDP Destination port
◆ udp_sport
| uint16_t rohc_comp_rfc5225_ip_udp_ctxt::udp_sport |
The UDP Source port
The documentation for this struct was generated from the following file:
