The ROHC compressor. More...
#include <rohc_comp_internals.h>
Data Fields | |
| struct rohc_medium | medium |
| rohc_comp_features_t | features |
| struct rohc_comp_ctxt * | contexts |
| uint16_t | num_contexts_used |
| struct hashtable | contexts_by_fingerprint |
| struct hashtable | contexts_cr |
| struct rohc_comp_ctxt * | uncompressed_ctxt |
| bool | enabled_profiles [ROHC_PROFILE_ID_MAJOR_MAX+1][ROHC_PROFILE_ID_MINOR_MAX+1] |
| uint8_t * | rru |
| size_t | rru_off |
| size_t | rru_len |
| rohc_rtp_detection_callback_t | rtp_callback |
| void * | rtp_private |
| int | num_packets |
| int | total_uncompressed_size |
| int | total_compressed_size |
| struct rohc_comp_ctxt * | last_context |
| rohc_comp_random_cb_t | random_cb |
| void * | random_cb_ctxt |
| uint8_t | oa_repetitions_nr |
| rohc_reordering_offset_t | reorder_ratio |
| size_t | periodic_refreshes_ir_timeout_pkts |
| uint64_t | periodic_refreshes_ir_timeout_time |
| size_t | periodic_refreshes_fo_timeout_pkts |
| uint64_t | periodic_refreshes_fo_timeout_time |
| size_t | mrru |
| rohc_trace_callback2_t | trace_callback |
| void * | trace_callback_priv |
Detailed Description
The ROHC compressor.
Field Documentation
◆ contexts
| struct rohc_comp_ctxt* rohc_comp::contexts |
The array of compression contexts that use the compressor
◆ contexts_by_fingerprint
| struct hashtable rohc_comp::contexts_by_fingerprint |
◆ contexts_cr
| struct hashtable rohc_comp::contexts_cr |
◆ enabled_profiles
| bool rohc_comp::enabled_profiles[ROHC_PROFILE_ID_MAJOR_MAX+1][ROHC_PROFILE_ID_MINOR_MAX+1] |
Which profiles are enabled and with one are not?
◆ features
| rohc_comp_features_t rohc_comp::features |
Enabled/disabled features for the compressor
◆ last_context
| struct rohc_comp_ctxt* rohc_comp::last_context |
The last context used by the compressor
◆ medium
| struct rohc_medium rohc_comp::medium |
The medium associated with the decompressor
◆ mrru
| size_t rohc_comp::mrru |
Maximum Reconstructed Reception Unit
◆ num_contexts_used
| uint16_t rohc_comp::num_contexts_used |
The number of compression contexts in use in the array
◆ num_packets
| int rohc_comp::num_packets |
The number of sent packets
◆ oa_repetitions_nr
| uint8_t rohc_comp::oa_repetitions_nr |
The nr of Optimistic Approach repetitions to gain transmission confidence
◆ periodic_refreshes_fo_timeout_pkts
| size_t rohc_comp::periodic_refreshes_fo_timeout_pkts |
The maximal number of packets sent in > FO states (= SO state) before changing back the state to FO (periodic refreshes)
◆ periodic_refreshes_fo_timeout_time
| uint64_t rohc_comp::periodic_refreshes_fo_timeout_time |
The maximal delay spent in > FO states (= SO state) before changing back the state to FO (periodic refreshes)
◆ periodic_refreshes_ir_timeout_pkts
| size_t rohc_comp::periodic_refreshes_ir_timeout_pkts |
The maximal number of packets sent in > IR states (= FO and SO states) before changing back the state to IR (periodic refreshes)
◆ periodic_refreshes_ir_timeout_time
| uint64_t rohc_comp::periodic_refreshes_ir_timeout_time |
The maximal delay spent in > IR states (= FO and SO states) before changing back the state to IR (periodic refreshes)
◆ random_cb
| rohc_comp_random_cb_t rohc_comp::random_cb |
The user-defined callback for random numbers
◆ random_cb_ctxt
| void* rohc_comp::random_cb_ctxt |
Private data that will be given to the callback for random numbers
◆ reorder_ratio
| rohc_reordering_offset_t rohc_comp::reorder_ratio |
The reorder offset specifies how much reordering is handled by the W-LSB encoding of the MSN in ROHCv2 profiles
◆ rru
| uint8_t* rohc_comp::rru |
The remaining bytes of the Reconstructed Reception Unit (RRU) waiting to be split into segments
◆ rru_len
| size_t rohc_comp::rru_len |
The number of the remaining bytes in the RRU buffer
◆ rru_off
| size_t rohc_comp::rru_off |
The offset of the remaining bytes in the RRU buffer
◆ rtp_callback
| rohc_rtp_detection_callback_t rohc_comp::rtp_callback |
The callback function used to detect RTP packet
◆ rtp_private
| void* rohc_comp::rtp_private |
Pointer to an external memory area provided/used by the callback user
◆ total_compressed_size
| int rohc_comp::total_compressed_size |
The size of all the sent compressed ROHC packets
◆ total_uncompressed_size
| int rohc_comp::total_uncompressed_size |
The size of all the received uncompressed IP packets
◆ trace_callback
| rohc_trace_callback2_t rohc_comp::trace_callback |
The callback function used to manage traces
◆ trace_callback_priv
| void* rohc_comp::trace_callback_priv |
The private context of the callback function used to manage traces
◆ uncompressed_ctxt
| struct rohc_comp_ctxt* rohc_comp::uncompressed_ctxt |
The documentation for this struct was generated from the following file:
